LED Module/

Edge-Lit Nichia LED Module

  • STH-F12P600W1L50
  • Product ID: 1.6W NICHIA LED Edge-Lit Module
  • LED Chip: high quality 3030 LED Nichia/Osram
  • Lumens:135LM/Module
  • Lens: Diffuse reflection optical processing 56*12degrees
  • Material: Aluminum PCB & ABS injection
  • High efficacy up to 120lm/W
  • Waterproof IP65

  • Product Details

NICHIA 1.6W Edge-Lit LED Module For Double-sided Lightboxes

Product name: Nichia Edge-Lit LED ModuleApplication:For double-side sign box illumination
LED type: NICHIA SMD3030 LEDs 1.0WattLED quantity: 1pcs
Physical dimension:50mm (L)*30mm (W)*11mm (H)Operating voltage: 12VDC
Storage Temperature:-50℃~80℃Color Rendering Index (CRI): 80
Power consumption: 1.6W/LEDOperating temperature:  -40℃~60℃
Emitting color: Pure White/ Warm WhiteLuminous output each color:150LM/pcs
Beam angle: 45º*15ºLife span: 50000 Hours
Protection grade: IP65Driven mode: Constant current
Weight:0.018KGPackage: 1000pcs per inner carton, 2 cartons in 1 box
Quantity to illuminate each  evenly:  20pcsMaterial: ABS injection & Aluminum PCB
Depth/Thickness of Signs:  10~20cm
